INTRODUCTION
The Digital Commander Series are COTS, Small Form Factor, Open Architecture computer systems which integrate field-tested, and proven Computer Conversions Corporation Converters. The system supports numerous transducer types including Synchro/Resolver/RVDT/LVDT. Input and output converters are available from 12bit to 16bit with frequencies ranging from 60Hz to 10Khz, for a maximum of 12 total channels.*
*see datasheet
FEATURES
• Rugged PC-104 SFF Computer System
• Windows / Linux / QNX Compatible
• Dual Gigabit Ethernet Ports
• Industrial Long-Life SSD
• DDR4 RAM
• 24VDC POWER
• Fanless Design
• Sealed Enclosure
• Fully EMI Shielded
• Sealed Connectors
• Integrated Internal and External Shock Mount System
• Multi-Channel Transducer Interface
• Supports Synchro/Resolver/RVDT/LVDT
• Fully Customizable Read / Write Channels
• Arinc-429 Optional
• MIL-STD-1553 Bus Support Optional
• Multi-Channel ADC-DAC Support Optional
( Designed to meet MIL-STD-810G, MIL-STD-461F and IP67 )
- Synchro to Digital
- Resolution:10 to 16 bit
- Accuracy:+/-40 arc seconds 16 bit
- Reference Inputs:11.8Vrms, 26Vrms, 115Vrms L-L
- 47 to 10,000 Hz.
- Signal Inputs:11.8, 26, 40, 90V.L-L.
- Options: Multispeed synchro input
- Digital to Synchro
- 1.2VA through 5VA Models
- Short Circuit, Transient and Thermally Protected Outputs with Isolation
- Self-Powered off the AC Reference Input
- High Accuracy, 10-16 Bit Resolution
-
- Digital to Synchro
- (Reference Powered)
- Only +5V DC Input Power Required
- Parallel Binary Angle Input
- No +15V DC Supplies Needed
- CMOS & TTL Compatible
- 14 or 16 Bits Natural Binary Angle Data Input
- Resolver to Digital
- Resolution:10 to 16 bit
- Accuracy:+/-40 arc seconds 16 bit
- Reference Inputs:11.8Vrms, 26Vrms, 115Vrms L-L
- 47 to 10,000 Hz.
- Signal Inputs:11.8, 26, 40, 90V.L-L.
- Options: Multispeed input
- Digital to Resolver
- 1.2VA through 5VA Models
- Short Circuit, Transient and Thermally Protected Outputs with Isolation
- Self-Powered off the AC Reference Input
- High Accuracy, 10-16 Bit Resolution
- 11.8V and 26V Outputs Standard
- Digital to LVDT/RVDT
- 3V and 5V logic Compatible
- 2 or 3-4 wire output configurations
- High Drive Capability of up to 2000 ohms
- virtually Indestructible Short-Circuit Proof outputs
- 3V to 28V Reference Inputs Typical
Customization
As a leader in the motion control industry for over 50 years Computer Conversions Corporation can customize a synchro / resolver data acquisition solution, or synchro / resolver simulation solution for your specific application. Whether you're using non-standard reference signals, high output power, or require a special combination of input and ouput devices, we are here to work with your engineering staff to develop a custom solution for your company.
Contact Our Team:
sales@computerconversions.com
(631) 261-3300
